The 8×10

Price range: 1500,00 € through 1910,00 €

A light (3.75kg) and very stable chamber.
It has almost all the movements available on a technical chamber.
Once folded, you can easily transport it on all your trips.
and set it up quickly for your shots.
/// Current lead times for manufacturing/delivery 8/10 weeks ///

Selected Features
Drink
Bellows
Engraving
Clear
+
Description

Product Details

Minimum extension: 120 mm
Maximum extension: 600 mm
Range of recommended focal lengths: from 120mm to 480mm
Dimensions of the closed box:
· Length: 338mm
· Width: 350 mm (with buttons)
· Height: 115 mm
Materials: Birch plywood, carbon fiber, anodized aluminum,
stainless steel screws, plastic buttons with stainless steel insert
Weight: 3.7 kg (with frosted glass and board)
Frosted: glass with acrylic Fresnel
Objective board: 140×140 mm (Sinar type)
· Includes set of 3 Copal boards (0, 1 and 3)
Tripod mounting: 3 mounting holes 3/8 inch + 1/4 inch adapter
Movements:
· front plane tilt: only limited by the bellows
· front plane tilt: only limited by the bellows
· front horizontal offset: -/+ 50mm
· front vertical offset: -/+ 70mm
· rear plane inclination: -/+ 25° only limited by the bellows
· rear plane tilt: -/+ 10°

Additional information
Weight3,75 kg
Drink

natural, black, stained or burned wood

Bellows

black, other color

Engraving

Yes, No thanks

Delivery & Return

We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.

Rules

All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.

Interpretation and Definitions

All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.

    people  are viewing this right now
SKU: N/A Categories: ,

Product Reviews

Reviews
  1. Didier Chaloin

    Hello, I wanted to understand what the engraving option consists of?
    Does an 8x10 come with a frosted/Fresnel glass? (Sorry, I'm still very new to large format photography! 🙂)
    THANKS

    • Alix

      Hello, please excuse the very late reply; I hadn't seen your message. The engraving option allows you to add engraving elements (text, design, image of your choice) to the front body and the frosted glass protector.
      All our rooms come with the frosted glass and Fresnel lens combo.
